| Product Name | Union |
| Type | C x C |
| Material | C12200/Cu-DHP/Brass |
| Standard | ASME B16.22, EN 1254 |
| Size Range | 3/8" x 3/8" ~ 3" x 3" (15mm x 15mm ~ 54mm x 54mm) |
| Transport Package | Sealing Bag + Carton Case/Wooden Pallet |
| Delivery Time | 7 ~ 10 days |
| Application | For plumbing, water supply, refrigeration, medical gas, etc. |
| Origin | China |
| ASME B16.22 | ||||
| Item No. | Nominal Size (inch) | Actual Size (inch) | Connection Type | Bag Quantity |
| A127010 | 3/8" | 1/2" | C x C | 25 |
| A127015 | 1/2" | 5/8" | C x C | 25 |
| A127020 | 3/4" | 7/8" | C x C | 10 |
| A127025 | 1" | 1-1/8" | C x C | 10 |
| A127032 | 1-1/4" | 1-3/8" | C x C | 5 |
| A127040 | 1-1/2" | 1-5/8" | C x C | 5 |
| A127050 | 2" | 2-1/8" | C x C | 1 |
| A127065 | 2-1/2" | 2-5/8" | C x C | 1 |
| A127080 | 3" | 3-1/8" | C x C | 1 |
| EN 1254 | |||
| Item No. | Size (mm) | Connection Type | Bag Quantity |
| E127015 | 15 x 15 | EA | 20 |
| E127018 | 18 x 18 | EA | 10 |
| E127022 | 22 x 22 | EA | 10 |
| E127028 | 28 x 28 | EA | 10 |
| E127035 | 35 x 35 | EA | 5 |
| E127042 | 42 x 42 | EA | 2 |
| E127054 | 54 x 54 | EA | 1 |
